OpenOPTI is an affordable open-source 3D microscope that utilizes Optical Projection Tomography (OPT) to create three-dimensional images of samples. This method allows for obtaining a 3D representation using visible light without the need for physical sectioning.
The model consists of the following components:
- USB microscope
- Mirror
- Stepper motor
- EasyDriver stepper motor driver
- 10W LED
- Variable buck-converter
- Arduino Nano
- Small AC/DC power supply
The total assembly cost is approximately $60.
Usage Instructions:
- Install Arduino firmware
- Install the Matlab CT Reconstruction Package
- Change the COM port in the Matlab script to your Arduino's current port
- Center and focus your sample in the camera frame
- Click Run and wait for completion
This model is perfect for anyone seeking an affordable way to obtain 3D images of microscopic samples.
